JT-520F Powder packing machine

Application:
Packing powder such as milk powder , coffee powder , flour , powder etc.
We could not find any corresponding parameters, please add them to the properties table
Product Description

Application:



Packing powder such as milk powder , coffee powder , flour , powder etc.





Technical parameters:



Type

JT-520F

Bag length

100-350mm(L)

Bag width

60-250mm(W)

Max width of roll film

520mm

Packing speed

10-70bags/min

Measuring range

3000g

Air consumption

0.65mpa

Gas consumption

0.4m³/min

Power voltage

220V/50HZ

Power

4KW

Dimension

(L)1500mm*(W)1170mm*(H)1650mm

Deadweight of machine

800Kg



Technology Charateristic:



  1. CE certification.
  2. Panasonic servo motor driven auger filler.
  3. Panasonic servo motor drawing film, double bellt, faster and more stable.
  4. Mitsubishi PLC computer touch screen, easy to operate.
  5. Siemens frequency changer, all the spare parts, are international brands.
  6. The forming tube with five-sides design, very easy to make the perfect stand up bag style.
  7. The heat transfer printer & automatic film correction motor and anti-static device are for optional.
